H100 2000 EFI Super Custom Limited (RZH100G) 1989 representative specification
1RZ-E- Displacement
- 1,998 cc
- Power
- 110 PS @ 5,200 rpm (net)
Rated at launch; petrol
Buyer's guide
9 min read
Toyota HiAce
Buyer's guide & specs
- Model span
- 1967-present
- For sale
- 44
- active now
On this page
Quick answer
This hub covers the Japanese Toyota HiAce, a cab-over van sold as a Wagon, a Van and a Commuter, in two generations: the H100, released on 24 August 1989, and the H200, on sale from 23 August 2004 and still updated in 2026. Use the generation pages for engines, grades, recalls and import age.
Background
Overview
The Toyota HiAce is a cab-over van that Toyota sells in Japan as a Wagon, a Van and a Commuter. This hub covers two generations: the H100, released on 24 August 1989, and the H200, on sale from 23 August 2004. Earlier generations and the overseas series are not covered; use the generation pages for engines, recalls and import age.
Quick read
Key takeaways
- Two generation pages: the H100 (released 24 August 1989) and the H200 (on sale from 23 August 2004).
- Engines depend on date: the H100 used RZ petrols and 2L-T, 3L, 5L and 1KZ-TE diesels; the H200 gained the 1KD-FTV (2007) and 1GD-FTV (2017).
- The H200 is still on sale in Japan: Toyota issued updates on 2 February and 1 July 2026.
- Toyota's 4WD became full-time in August 1993, with no centre-differential lock or auxiliary transmission.
- Import age is judged per car from its manufacture date; EPA's engine rule and Canada's bus rule apply separately.
Constants
Common across all HiAce generations
- Cab-over van layout in Wagon, Van and Commuter bodies
- Rear-wheel drive or 4WD depending on configuration; Toyota's 4WD became full-time in August 1993
- Petrol and diesel engines that change by body and date
- Japanese-market records only; export specifications need separate evidence
Chassis history
Generation timeline
Dates are Toyota's Japanese release or sale dates. Each generation page has its own specification tables and checklist.
Identification
Chassis-code reference
Generation names are broad families. The factory chassis codes below identify the variants represented in JDMBUYSELL's current Toyota HiAce guide data.
- Fourth generation — H100 (1989–2004)
- Chassis code: KZH100
- Fifth generation — H200 (2004–present)
- Chassis codes: KDH201V, KDH221K, TRH224W, and GDH201V
Confirm the complete code on the vehicle's frame or VIN plate; drivetrain, body, and market variants can use different prefixes within one generation family.
Market
Differences between JDM & USDM
This guide covers the Japanese HiAce and uses Toyota's Japanese releases, sheets and ratings. The overseas series that Toyota unveiled in the Philippines in 2019 is separate, and no export-market specification is stated here.
Specs
Technical specifications
Engine options
-
-
H100 2400 EFI Super Custom Limited (RZH101G) 1989 representative specification
2RZ-E- Displacement
- 2,438 cc
- Power
- 120 PS @ 4,800 rpm (net)
Rated at launch; petrol
-
H100 2400 diesel turbo Super Custom Limited (LH100G) 1989 representative specification
2L-T- Displacement
- 2,446 cc
- Aspiration
- Turbo diesel
- Power
- 94 PS @ 4,000 rpm (net)
-
H100 Custom Wagon (Y-KZH100G) Aug 1993 catalogue
1KZ-TE- Displacement
- 2,982 cc
- Aspiration
- Turbo diesel
- Power
- 130 PS (96 kW) @ 3,600 rpm
- Torque
- 289.3 Nm (29.5 kgf·m) @ 2,000 rpm
- Transmission
- 5-speed manual, rear-wheel drive
-
H100 Deluxe Long Wagon (E-RZH111G) Aug 1996 catalogue
2RZ-E- Displacement
- 2,438 cc
- Power
- 120 PS (88 kW) @ 4,800 rpm
- Torque
- 198.1 Nm (20.2 kgf·m) @ 2,600 rpm
- Transmission
- 4-speed automatic (ECT), rear-wheel drive
-
H100 Super Custom G 4WD (KH-KZH106W) Jul 1999 catalogue
1KZ-TE- Displacement
- 2,982 cc
- Aspiration
- Intercooled turbo diesel
- Power
- 130 PS (96 kW) @ 3,600 rpm
- Torque
- 331.5 Nm (33.8 kgf·m) @ 2,000 rpm
- Transmission
- 4-speed automatic (ECT), full-time 4WD
Water-cooled intercooler added July 1999
-
H200 diesel Van and Commuter Aug 2004 launch
2KD-FTV- Displacement
- 2,494 cc
- Aspiration
- Intercooled direct-injection turbo diesel
- Power
- 109 PS (80 kW) @ 3,400 rpm
- Torque
- 260 Nm (26.5 kgf·m) @ 1,600–2,600 rpm
-
H200 2.0 petrol Van Aug 2004 launch
1TR-FE- Displacement
- 1,998 cc
- Aspiration
- VVT-i inline four, DOHC
- Power
- 133 PS (98 kW) @ 5,600 rpm
- Torque
- 182 Nm (18.6 kgf·m) @ 4,000 rpm
-
H200 2.7 petrol Wagon, Commuter and super-long Van Aug 2004 launch
2TR-FE- Displacement
- 2,693 cc
- Aspiration
- VVT-i inline four, DOHC
- Power
- 151 PS (111 kW) @ 4,800 rpm
- Torque
- 241 Nm (24.6 kgf·m) @ 3,800 rpm
-
H200 Van 1KD-FTV Mar 2015 specification sheet
1KD-FTV- Displacement
- 3.0 L
- Aspiration
- Direct-injection turbo diesel
- Power
- 144 PS (106 kW) @ 3,400 rpm
- Torque
- 300 Nm (30.6 kgf·m) @ 1,200–3,200 rpm
Introduced on diesel models 20 August 2007
-
H200 Van 2TR-FE Mar 2015 specification sheet
2TR-FE- Displacement
- 2.7 L
- Power
- 160 PS (118 kW) @ 5,200 rpm
- Torque
- 243 Nm (24.8 kgf·m) @ 4,000 rpm
-
H200 Van 1TR-FE Mar 2015 specification sheet
1TR-FE- Displacement
- 2.0 L
- Power
- 136 PS (100 kW) @ 5,600 rpm
- Torque
- 182 Nm (18.6 kgf·m) @ 4,000 rpm
-
H200 Van 1GD-FTV Feb 2025 specification sheet
1GD-FTV- Displacement
- 2.8 L
- Aspiration
- Diesel with DPR and urea SCR
- Power
- 151 PS (111 kW) @ 3,600 rpm
- Torque
- 300 Nm (30.6 kgf·m) @ 1,000–3,400 rpm
- Transmission
- 6-speed automatic
Standard configurations; DARK PRIME S is not covered by this figure. Introduced 1 December 2017
Lineup
Variants & trims
| Generation | Trim | Engine | Key features |
|---|---|---|---|
| H100 (fourth generation, Japan) | Custom Wagon (August 1993) | 1KZ-TE, 130 PS | Nine seats; rear-wheel drive; five-speed manual; 4,640 x 1,690 x 1,950 mm; 1,850 kg; power-assisted rack and pinion steering; dual air conditioning. |
| H100 (fourth generation, Japan) | Deluxe Long Wagon (August 1996) | 2RZ-E, 120 PS | Ten seats; four-speed automatic; 4,900 x 1,690 x 1,960 mm on a 2,590 mm wheelbase; 1,710 kg; driver and passenger airbags and ABS standard. |
| H100 (fourth generation, Japan) | Super Custom Wagon (July 1999) | 2RZ-E petrol or 1KZ-TE diesel | Eight seats; semi-middle roof. |
| H100 (fourth generation, Japan) | Super Custom G Wagon (July 1999) | 2RZ-E petrol or 1KZ-TE diesel | Eight seats; triple moonroof. The KH-KZH106W 4WD example is 4,690 x 1,690 x 2,025 mm at 2,090 kg with full-time 4WD and a four-speed automatic; catalogue economy 8.5 km/L (10-mode/10-15-mode, not a road result). |
| H100 (fourth generation, Japan) | Super Custom Limited Wagon (July 1999) | 2RZ-E petrol or 1KZ-TE diesel | Seven seats; triple moonroof; second-row captain seats added in the July 1999 update; woodgrain-effect steering wheel rim. |
| H100 (fourth generation, Japan) | Grand Cabin G-p and G-e Wagon (July 1999) | 1KZ-TE, intercooled turbo diesel | Ten seats; high roof; super-long; two-wheel drive. |
| H100 (fourth generation, Japan) | Living Saloon EX Wagon (July 1999) | 2RZ-E; 1KZ-TE in 2WD and 4WD | Special specification based on the Super Custom G; eight seats; triple moonroof. |
| H100 (fourth generation, Japan) | DX Van (July 1999) | 1RZ-E, 2.0-litre petrol | Standard van; three or six seats; two-wheel drive; five-speed manual. |
| H100 (fourth generation, Japan) | GL Package Van (July 1999) | 5L, 3.0-litre diesel | Long van; three or six seats; four-wheel drive. |
| H100 (fourth generation, Japan) | Super GL Van (July 1999) | 5L, 3.0-litre diesel | Long van; two or five seats; two-wheel drive; four-speed automatic. A wireless door-lock remote with answer-back was added in August 2002. |
| H100 (fourth generation, Japan) | Commuter DX (July 1999) | 2RZ-E | 15 seats; super-long; high roof; two-wheel drive; four-speed automatic. |
| H200 (fifth generation, Japan) | Van DX and DX GL Package | Launch: 1TR-FE or 2TR-FE petrol, 2KD-FTV diesel | Commercial grades. The GL Package was added to DX on 20 August 2007. The long standard-roof three-seat DX has a 3,000 mm load length. |
| H200 (fifth generation, Japan) | Van Super GL | Launch: 1TR-FE petrol or 2KD-FTV diesel | A Van grade, separate from Wagon GL. Wide-body version added 20 August 2007; dual power sliding doors optional from December 2013; LED front fog lamps standard from April 2022. |
| H200 (fifth generation, Japan) | Wagon DX and GL | 2TR-FE petrol at launch | Ten seats. At launch the DX was long, wide, middle roof, with a four-speed automatic. The GL grade was added on 20 August 2007. |
| H200 (fifth generation, Japan) | Wagon Grand Cabin (December 2017 example, CBA-TRH224W) | 2TR-FE, 160 PS | Ten seats; super-long wide high-roof; rear-wheel drive; six-speed automatic; 5,380 x 1,880 x 2,285 mm on a 3,110 mm wheelbase; 2,040 kg; live rear axle on leaf springs. |
| H200 (fifth generation, Japan) | Commuter DX and GL | DX 2TR-FE petrol; GL 2KD-FTV (2004) or 1KD-FTV (2013) | Super-long wide high-roof. Fifteen seats announced in 2004; 14 seats in the December 2013 matrix. |
| H200 (fifth generation, Japan) | Van Super GL DARK PRIME (January 2015) | 1TR-FE, 2TR-FE or 1KD-FTV | Dark-grey tricot with synthetic leather and double stitching. |
| H200 (fifth generation, Japan) | Van Super GL DARK PRIME II (August 2018) | 1TR-FE, 2TR-FE or 1GD-FTV | Black roof, pillars and separator bar; passenger airbag and belt with pretensioner and force limiter standard. |
| H200 (fifth generation, Japan) | Van Super GL 50th Anniversary Limited (August 2018) | 1TR-FE or 2TR-FE petrol; 1GD-FTV diesel | Time-limited production planned through 31 July 2019; anniversary emblem on the back door; dark-brown seats; dual power sliding doors standard. No unit cap is published. |
| H200 (fifth generation, Japan) | Van Super GL DARK PRIME S (February 2025) | 2.8-litre diesel with DARK PRIME S calibration | Standard-body Van with a 2.8-litre diesel and dedicated shock absorbers. Its engine calibration is not covered by the standard 1GD figures. |
Gallery
In pictures
Editorial
The buyer's read
Choose the generation first, then the build date. The H100 is dated from 24 August 1989 and its engines change by body and year; the H200 is dated update by update from 23 August 2004.
Then confirm the body and engine from the plate. For a diesel H200, ask for proof of Toyota's 2012 and 2016 recall work, and check the AdBlue records on a 1GD-FTV.
Last, work out the car's age from its manufacture date. EPA's engine rule applies separately, and Canada treats buses under a different rule, which a Commuter buyer should check.
FAQ
Frequently asked questions
- Which HiAce generations does this hub cover?
- The H100, released in Japan on 24 August 1989, and the H200, on sale from 23 August 2004. Earlier generations and the overseas series are not covered.
- Is the H200 still on sale in Japan?
- Yes. Toyota said in 2019 that the current model would continue to be sold in Japan as-is, and it issued updates that went on sale on 2 February and 1 July 2026.
- Which diesel engines did the H100 and H200 use?
- The H100 used the 2L-T, 3L, 5L and 1KZ-TE, depending on body and date. The H200 began with the 2KD-FTV and gained the 1KD-FTV on 20 August 2007 and the 1GD-FTV on 1 December 2017.
- Can I import a HiAce to the US or Canada?
- The US 25-year rule runs from each car's manufacture date, and EPA separately expects the original-design engine or a certified replacement. Canada counts 15 years from the manufacture month and treats buses separately.
