Chassis Code Explained
| Segment | Meaning | Detail |
|---|---|---|
| E24 | Series designation | Third-generation Caravan series (Nissan Heritage Collection); the digits are Nissan's series code, not a generation count |
| KEE24, KD-ARE24, KD-KRGE24, FEGE24 | Full model codes in the sources used | 1992 Limousine, 1995 Limousine, 1995 Coach DX and 1993 ambulance; the prefixes and middle letters differ by grade, engine, drive and body |
Nissan does not publish a letter-by-letter breakdown in the sources used. Match the full plate code to a dated catalogue entry.
Editorial notes
Key Takeaways
Dates are Nissan's Japanese dates. Nissan labels the generation 1986–2001; the label is not an exact build range.
- E24 is Nissan's third-generation Caravan, introduced in Japan in September 1986; Nissan labels the generation 1986–2001.
- Passenger Coach grades and commercial vans are catalogued separately, and the June 1999 revision ended the Coach range.
- TD27 ratings differ by engine: 85 PS naturally aspirated (1994), 100 PS TD27T (1990–1993), 130 PS TD27ETi (1995).
- Part-time 4WD is documented on specific Coach codes and, in the 1999 van table, on QD32 long-body vans.
- The 1999 payload rise to 1.25 tonnes excludes super-long and flat-floor vans and applies to 2WD only.
- US eligibility is judged on each car's own age, and EPA expects the original-design engine or a certified replacement.
Background
Passenger Coach grades and model codes
Motor-Fan's August 1995 table lists the Coach grades with their codes. Limousine and Royal seat seven, GT Cruise and GT Cruise S seat eight, Coach GL seats eight or nine and Coach DX ten. Rear-wheel-drive codes include E-KEE24 (2,960 cc, 4-speed automatic), KD-ARE24 and KD-KRGE24 (2,663 cc); part-time 4WD appears on KD-ARME24, KD-ARMGE24, KD-KRMGE24 and KD-KRME24.
One code can cover more than one grade: KD-ARE24 is listed for the Limousine and for GT Cruise. Nissan's heritage page dates the Royal grade to 1990 and the 2,960 cc VG30 engine to 1988. The August 1994 Silkroad is listed as Y-KRME24, an eight-seat part-time 4WD diesel with a 5-speed manual.
The diesels are not interchangeable
The TD27 diesels appear at three outputs in the catalogue entries used here. The August 1994 Silkroad lists a naturally aspirated TD27 of 2,663 cc at 85 PS (63 kW) and 176.5 Nm. A GT diesel turbo in the August 1990 to April 1993 catalogue period lists the TD27T at 100 PS.
The August 1995 Limousine lists the TD27ETi, an intercooled turbo with electronically controlled injection, at 130 PS (96 kW) and 278.5 Nm (28.4 kgf·m). The entries do not state a gross or net basis, so do not apply one rating to a generic TD27. Nissan's heritage pages name the 2,960 cc V6 as VG30 in the Limousine and VG30E in the ambulance, both at 155 PS (114 kW) and 245 Nm.
June 1999 and the commercial vans
Nissan's 1 June 1999 release changed the commercial range. Vans gained the twin-cam KA20DE and KA24DE petrol engines and 15-inch tyres and brakes, and the QD32 diesel continued. The Caravan and Homy names were merged into Caravan and the Coach range was dropped. The price table lists DX-S, DX, GL-L and VX grades: standard-body DX-S, GL-L and VX with KA20DE or QD32, the long-body VX with KA24DE or QD32, and 4WD long-body vans with QD32 only.
Transmissions are a 5-speed manual or an electronically controlled 4-speed automatic. A 15-seat microbus (DX, super-long, high-roof, low-floor) used the QD32. Autech added a compressed-natural-gas van, the CNGV, on 1 December 1999.
Dimensions of documented examples
Nissan's heritage page documents a 1992 KEE24 Limousine (2WD): 4,525 × 1,725 × 1,955 mm on a 2,375 mm wheelbase, 1,450/1,415 mm tracks, 1,860 kg vehicle weight and 205/70R15 95H tyres. It has double-wishbone front and longitudinal-leaf rear suspension, ventilated front discs with rear drums, power seats, ASCD and electronically controlled suspension. The August 1995 diesel Limousine (KD-ARE24) is the same size at 1,960 kg, and the August 1994 Silkroad is 4,525 × 1,690 × 1,990 mm at 1,920 kg. They describe those examples only.
Ambulance and recall 791
Nissan's heritage collection preserves a 1993 FEGE24 Hyper-Pack ambulance: 5,130 × 1,690 × 2,470 mm, 1,950 kg, with a 2,960 cc VG30E V6 at 155 PS (114 kW) and 245 Nm. Recall 791 (announced 22 November 2001) covers 79 high-standard E-FEGE24 ambulances built from 22 November 1994 to 18 April 1997. The fusible-link capacity and terminal shape could overheat and interrupt the lights, horn and defroster circuits; Nissan's remedy was a new link holder and replacement links. A recall population is not total production, and the sources used do not show that ordinary vans or Coaches are covered.
Technical Specifications
Figures come from Nissan heritage pages and dated Japanese catalogues, each tied to its code and date. Catalogue entries do not state a gross or net basis.
Engine Options
-
E24 Limousine (KEE24) 1992 heritage example
VG30- Displacement
- 2,960 cc
- Power
- 155 PS (114 kW) @ 5,200 rpm
- Torque
- 245 Nm (25.0 kgf·m) @ 3,200 rpm
Nissan's 1992 KEE24 Limousine 2WD example: V6 OHC; rating basis not stated; 1,860 kg vehicle weight.
-
E24 Silkroad (Y-KRME24) Aug 1994 catalogue
TD27- Displacement
- 2,663 cc
- Aspiration
- Naturally aspirated diesel
- Power
- 85 PS (63 kW) @ 4,300 rpm
- Torque
- 176.5 Nm (18.0 kgf·m) @ 2,200 rpm
- Transmission
- 5MT, part-time 4WD
Motor-Fan's August 1994 Silkroad Y-KRME24 entry: 96.0 × 92.0 mm, 21.8:1; distributor-type injection pump; eight seats, 1,920 kg.
-
E24 GT diesel turbo (KRE24) Aug 1990 – Apr 1993 catalogue
TD27T- Displacement
- 2,663 cc
- Aspiration
- Turbo diesel
- Power
- 100 PS @ 4,000 rpm
- Transmission
- 4AT, rear-wheel drive
Response's August 1990–April 1993 GT diesel-turbo KRE24 entry: eight seats, 1,870 kg.
-
E24 Limousine (KD-ARE24) Aug 1995 catalogue
TD27ETi- Displacement
- 2,663 cc
- Aspiration
- Intercooled turbo diesel
- Power
- 130 PS (96 kW) @ 4,000 rpm
- Torque
- 278.5 Nm (28.4 kgf·m) @ 2,000 rpm
- Transmission
- 4AT, rear-wheel drive
Motor-Fan's August 1995 Limousine KD-ARE24 entry: 96.0 × 92.0 mm, 22.3:1; electronically controlled injection; seven seats, 1,960 kg.
-
E24 Hyper-Pack ambulance (FEGE24) 1993 heritage example
VG30E Comparison- Displacement
- 2,960 cc
- Power
- 155 PS (114 kW) @ 5,200 rpm
- Torque
- 245 Nm (25.0 kgf·m) @ 3,200 rpm
Comparison: Nissan's 1993 FEGE24 Hyper-Pack ambulance example; V6 OHC; 1,950 kg curb weight. These are ambulance specifications.
Transmission Options
| Type | Availability | Notes |
|---|---|---|
| 5-speed manual | Coach DX and GL (KD-KRGE24, KD-KRMGE24, KD-KRME24), the August 1994 Silkroad and the 1999 DX-S vans | Availability depends on grade, engine and drive. |
| 4-speed automatic | Limousine, Royal and GT Cruise grades in 1995, and some DX and GL Coaches | Nissan's 1999 van table calls it an electronically controlled 4-speed automatic (E-AT). A 3-speed automatic is not documented in the sources used. |
Variants & Trims
Coach grades and commercial van grades are shown separately, each with the catalogue date that identifies it.
| Generation | Trim | Engine | Key Features |
|---|---|---|---|
| E24 (third generation, Japan) | Limousine, KEE24 (1992 heritage example) | VG30 V6, 2,960 cc, 155 PS | Two-wheel drive passenger Coach. Power seats, ASCD and electronically controlled suspension; 4,525 × 1,725 × 1,955 mm; 1,860 kg. |
| E24 (third generation, Japan) | Limousine, KD-ARE24 (Aug 1995) | TD27ETi diesel, 2,663 cc, 130 PS | Seven seats, rear-wheel drive, 4-speed automatic; driver's airbag, dual air conditioning and twin sunroof; 1,960 kg. |
| E24 (third generation, Japan) | Limousine, E-KEE24 and KD-ARME24 (Aug 1995) | 2,960 cc petrol (E-KEE24); 2,663 cc diesel (KD-ARME24) | Seven seats and a 4-speed automatic on both. KD-ARME24 has part-time 4WD; the catalogue table does not name the diesel engine. |
| E24 (third generation, Japan) | Royal, E-AEGE24 and KD-ARMGE24 (Aug 1995) | 2,960 cc petrol (E-AEGE24); 2,663 cc diesel (KD-ARMGE24) | Seven seats, 4-speed automatic. KD-ARMGE24 has part-time 4WD. Nissan's heritage page dates the Royal to 1990, with power seats, an LCD colour television and twin automatic air conditioning. |
| E24 (third generation, Japan) | GT Cruise and GT Cruise S (Aug 1995) | E-KEE24 2,960 cc; KD-ARE24 and KD-ARME24 2,663 cc | Eight seats and a 4-speed automatic. KD-ARME24 has part-time 4WD; the other two codes are rear-wheel drive. |
| E24 (third generation, Japan) | 2.7 GT diesel turbo, KRE24 (Aug 1990 – Apr 1993) | TD27T diesel, 2,663 cc, 100 PS | Eight seats, 4-speed automatic, rear-wheel drive; 1,870 kg in the catalogue. |
| E24 (third generation, Japan) | Coach DX and GL (Aug 1995) | 2,663 cc diesel | DX: KD-KRGE24 (rear-drive, 5-speed manual or 4-speed automatic) and KD-KRMGE24 (part-time 4WD, 5-speed manual), ten seats. GL: KD-KRE24 (nine seats) and KD-KRME24 (part-time 4WD, eight seats). |
| E24 (third generation, Japan) | Silkroad, Y-KRME24 (Aug 1994) | TD27 diesel, 2,663 cc, 85 PS | Eight seats, part-time 4WD, 5-speed manual; 4,525 × 1,690 × 1,990 mm; 1,920 kg. |
| E24 (third generation, Japan) | Commercial van DX-S, DX, GL-L and VX (June 1999) | KA20DE, KA24DE or QD32 | Standard-body DX-S, GL-L and VX use KA20DE or QD32; the long-body VX uses KA24DE or QD32; 4WD long-body vans use QD32. 5-speed manual or 4-speed automatic by grade. |
| E24 (third generation, Japan) | Microbus DX (June 1999) | QD32 diesel | Super-long, high-roof, low-floor, 15 seats, 2WD, 5-speed manual or 4-speed automatic. |
| E24 (third generation, Japan) | CNGV (Autech, December 1999) | KA20 CNG specification | Compressed-natural-gas conversion of the 2WD light van, low floor, 3/6-seat, DX petrol 2000, with two 57 L cylinders in the load area. 5-speed manual. |
| E24 (third generation, Japan) | Hyper-Pack ambulance, FEGE24 (1993) | VG30E V6, 2,960 cc, 155 PS | Special body, 5,130 × 1,690 × 2,470 mm, 1,950 kg curb weight; covered by recall 791 if its chassis number is listed. |
Should You Buy a Nissan Caravan E24?
Strengths and cautions come from Nissan's releases and dated catalogues, not from failure statistics.
Why You'll Love It
- Dated grade and code tables Nissan's June 1999 release and Motor-Fan's August 1995 table tie grades to codes, seats, engines and drive, so a car can be matched to a documented entry.
- Part-time 4WD on listed codes Motor-Fan lists part-time 4WD Silkroad, GT Cruise S, Coach DX, Coach GL and Royal codes in its 1994 and 1995 entries.
- A wide choice of bodies Nissan's 1999 table covers standard, long, high-roof and super-long vans and a 15-seat microbus; the 1995 Coach table seats seven to ten.
Why You Might Not
- Figures do not transfer between grades TD27 is rated 85 PS, TD27T 100 PS and TD27ETi 130 PS in the entries used here, and the Limousine, Silkroad and ambulance each have their own weights.
- Gaps in the record The sources used do not establish exact build dates, a production total or KA20DE, KA24DE and QD32 power ratings for the E24.
- Coach and van are different cars Nissan dropped the Coach range in June 1999, so Coach grades and the 1999 commercial van grades do not share a specification.
Who Should NOT Buy This
- Anyone who wants a Coach built after the June 1999 revision: Nissan dropped the Coach range then.
- Anyone planning an engine swap before a US import: EPA expects the original-design engine or an EPA-certified replacement.
- Anyone importing a 12 or 15-seat microbus to Canada on the ordinary 15-year rule without checking classification: Transport Canada treats buses separately.
Common Issues & Solutions
Only Nissan's recall notice and a code-identification caution are listed; no general failure rates were established.
| Issue | Cause | Solution |
|---|---|---|
| Ambulance fusible links (recall 791) | Nissan recall 791 covers 79 high-standard E-FEGE24 ambulances built 22 November 1994 to 18 April 1997. Link capacity and terminal shape could overheat and interrupt the lights, horn and defroster. | Check an ambulance conversion's chassis number against the recall; Nissan's remedy was a new link holder and replacement links. |
| One code on several grades | Motor-Fan's August 1995 table lists KD-ARE24 for both the Limousine and GT Cruise grades, so a code alone does not identify the grade or seat count. | Match the full plate code, the seat count and the engine to a single dated catalogue entry. |
Differences between JDM & USDM
This page describes Japanese-market E24 Caravans from Nissan's own pages and dated Japanese catalogues. Export-market versions need their own evidence for engines, emissions systems and passenger classification and are not described here. Nissan's June 1999 release states that the Caravan and Homy names were merged into Caravan.
Pre-Purchase Inspection Checklist
Critical Priority
High Priority
Medium Priority
Generation History
Generation span (Nissan label) (1986–2001)
- Nissan's heritage index labels the E24 as 1986–2001; exact first and last build dates are not established
- Japanese introduction: September 1986, listed with the Homy in Nissan's corporate history
VG30 and the Royal grade (1988–1990)
- 1988: Nissan added the 2,960 cc VG30 engine to the passenger range
- 1990: Royal grade added with power seats, an LCD colour television and twin automatic air conditioning
Coach grades by catalogue date (1990–1995)
- August 1990 to April 1993 catalogue period: GT diesel turbo with the TD27T at 100 PS
- August 1994: Silkroad with the naturally aspirated TD27 at 85 PS and part-time 4WD
- August 1995: Limousine KD-ARE24 with the TD27ETi at 130 PS
June 1999 revision (1999)
- Vans gained KA20DE and KA24DE petrol engines; the QD32 diesel continued
- Caravan and Homy merged into Caravan and the Coach range was dropped
- Payload rose from 1 to 1.25 tonnes on 2WD vans except super-long and flat-floor bodies
- Autech announced the CNGV on 8 November 1999, on sale 1 December
Ambulance recall 791 (2001)
- Announced 22 November 2001 for 79 high-standard E-FEGE24 ambulances built 1994–1997
In Pictures
The Buyer's Read
Start with the plate code. Coach, van and microbus E24s are catalogued separately, and one grade name can sit on several codes and engines. Ask for the full model code and match it to a dated entry: the August 1995 Coach table, the August 1994 Silkroad or Nissan's June 1999 van table.
Then match the engine. The TD27 family is rated 85, 100 and 130 PS in the entries used here and the VG30 V6 155 PS, so a quoted figure helps only if it names the engine, the grade and the date. Part-time 4WD is documented on specific Coach codes and, in 1999, on QD32 long-body vans.
The sources used give no exact build dates or production totals, and they do not show that ordinary vans are covered by the ambulance recall. Treat claims about rarity or build year as unverified until the seller shows documents.
For the US, age is judged per car and EPA expects the original-design engine or a certified replacement. Canada counts 15 years from the manufacture month and treats buses and staged conversions separately, so ask for the build date on the compliance label before you commit.
Frequently Asked Questions
- Is the E24 the third or fourth Caravan generation?
- Third. Nissan's heritage page describes the 1986 E24 as the third generation. Nissan dates its Japanese introduction to September 1986 and labels the generation 1986–2001, but exact build dates are not established.
- Which E24 grades are passenger Coaches?
- Motor-Fan's August 1995 table lists Coach DX, GL, GT Cruise, GT Cruise S, Limousine and Royal, and an August 1994 entry lists the Silkroad. Nissan's 1 June 1999 release says the Coach range was dropped.
- How much power does the diesel E24 make?
- It depends on the engine. Motor-Fan lists the naturally aspirated TD27 at 85 PS in its August 1994 Silkroad entry and the TD27ETi at 130 PS in its August 1995 Limousine entry. Response lists the TD27T at 100 PS for the GT in its August 1990–April 1993 catalogue period. These entries do not state gross or net.
- Which E24s have 4WD?
- Part-time 4WD is documented on KD-ARME24, KD-ARMGE24, KD-KRMGE24 and KD-KRME24 in the August 1995 table, and on the August 1994 Silkroad. In Nissan's June 1999 van table, the 4WD long-body vans use the QD32 diesel.
- What changed in June 1999?
- Vans gained KA20DE and KA24DE petrol engines, the QD32 diesel continued, Homy was merged into Caravan and the Coach range was dropped. Payload rose from 1 to 1.25 tonnes on 2WD vans except super-long and flat-floor bodies.
- Can I import an E24 into the US or Canada?
- The US safety exemption applies when a vehicle is 25 or more years old (49 CFR 591.5(i)), judged on each car's own age; the model year does not decide it. EPA separately expects the original-design engine or an EPA-certified replacement. Canada's older-vehicle exemption covers vehicles older than 15 years, using the manufacture month and year; Transport Canada treats buses and vehicles built in stages separately.
