Key Takeaways
- Honda announced and sold the EK9 on 22 August 1997; the facelift followed on 4 September 1998 and the TYPE R・X on 16 December 1999.
- The B16B is rated 185 PS net at 8,200 rpm and 16.3 kgf·m at 7,500 rpm, with an 8,400 rpm limit.
- Honda lists a torque-sensitive helical LSD and a five-speed manual only.
- A race-base car and an equipment-delete option were documented at launch, so missing seats or air conditioning does not by itself show a fake.
- Honda's archive ends the model in September 2001; the factory's last build month is not established.
- The US 25-year rule runs from each car's build date, and EPA's engine rule applies separately.
Background
Grades and codes
Honda's August 1997 specification lists the type code E-EK9 for the TYPE R and for a race-base car in the same table. The race-base car is listed at 1,040 kg without power steering and 1,050 kg with it. The road TYPE R is listed at 1,070 kg with power steering, ABS and SRS airbags, and 1,090 kg with air conditioning as well, all under Honda's own vehicle-mass convention. Honda also documents an equipment-delete option.
Honda's own Type R history lists the EK9 as the first-generation Civic Type R. The TYPE R・X was announced and sold from 16 December 1999.
B16B engine
The B16B displaces 1,595 cc (81.0 × 77.4 mm) with 10.8:1 compression and belt-driven DOHC, and runs on unleaded premium petrol. Honda rates it at 185 PS net at 8,200 rpm and 16.3 kgf·m (about 160 N·m) at 7,500 rpm, and raised the engine speed limit from 8,200 to 8,400 rpm.
For the valvetrain Honda describes elliptical-section double valve springs. It also describes a process of hand-polishing the inside of the ports, engine by engine. The wording covers the ports only.
Gearbox and differential
Honda lists a five-speed manual only, with ratios of 3.230, 2.105, 1.458, 1.107 and 0.848 and a 4.400 final drive. The TYPE R carries a torque-sensitive helical limited-slip differential.
The cars are front-wheel drive with 195/55R15 84V tyres on five-hole wheels (114.3 mm pitch circle, 50 mm offset). Suspension is double-wishbone at the front and rear.
Body and cabin
Honda reports 35% more torsional rigidity than the base Civic, with added performance rods and substantial reinforcement around the tailgate opening. The launch car measures 4,180 × 1,695 × 1,360 mm on a 2,620 mm wheelbase and seats four; do not apply the launch length to facelift cars.
The road TYPE R has red Recaro bucket seats, a MOMO steering wheel and a machined titanium shift knob. Qualify those by grade and by the deletion options Honda documented.
Market and production
Evo reports that Honda never officially sold the EK9 in the UK, so UK-registered cars are imports. No reconciled production ledger exists in the sources used. Honda's American retrospective says about 15,900 were sold over a two-year period it states, and a PistonHeads feature says Honda produced just over 16,000 for the Japanese market, 9,205 of them facelifted. The figures use different bases. This guide does not give a total or a facelift majority.
Importing
For the US, the federal safety exemption is judged on each car's own manufacture date (49 CFR 591.5(i)): the vehicle must be at least 25 years old, so a model-year label proves nothing and the build month is what counts. EPA's age rule is separate. Its procedure describes 21 original-production years, an original unmodified configuration, and an exception for equivalent or newer EPA-certified engines and emission-control systems.
EPA's current guidance asks for the same engine model and configuration as the original, so consult EPA before relying on it for a modified or swapped car. State registration and emissions rules are not covered here. Canada treats vehicles older than 15 years as non-regulated at import, with age taken from the manufacture month and year; a right-hand-drive car should be checked against the destination province's registration rules.
Technical Specifications
Figures are Honda's Japanese net ratings from the August 1997 launch specification.
Engine Options
-
TYPE R, race-base Aug 1997 launch
B16B DOHC VTEC- Displacement
- 1,595 cc
- Power
- 185 PS @ 8,200 rpm (net)
- Torque
- 16.3 kgf·m @ 7,500 rpm (net)
- Transmission
- 5MT, FWD
81.0 × 77.4 mm, 10.8:1, belt-driven DOHC, unleaded premium, 8,400 rpm limit. About 160 N·m by conversion.
Transmission Options
| Type | Ratios | Availability | Notes |
|---|---|---|---|
| 5-speed manual | 3.230 / 2.105 / 1.458 / 1.107 / 0.848; final drive 4.400 | Road TYPE R and race-base | From Honda's August 1997 specification; the TYPE R carries a torque-sensitive helical LSD. |
NHTSA's safety exemption starts 25 years from each car's manufacture date under 49 CFR 591.5(i). EPA's separate age provision requires the original engine configuration or an eligible EPA-certified replacement engine and emissions system. State registration rules vary. Canada counts its 15-year federal age exemption by manufacture month and year. Check the car's documents before shipping. Calculate import costs →
Sources: 49 CFR 591.5 (eCFR) ; EPA: learn about importing vehicles and engines ; EPA: importing vehicles and engines guidance (NEPIS) ; CBSA Memorandum D9-1-11
Variants & Trims
Rows follow Honda's documented grades: the road TYPE R, the race-base car and the TYPE R・X.
| Generation | Trim | Engine | Key Features |
|---|---|---|---|
| EK9 three-door hatchback (Japan) | TYPE R (E-EK9) | B16B, 185 PS | Five-speed manual; torque-sensitive helical LSD; red Recaro seats, MOMO wheel and titanium shift knob; 1,070 kg with power steering, ABS and SRS, or 1,090 kg with air conditioning as well. |
| EK9 three-door hatchback (Japan) | Race-base (documented at the August 1997 launch) | B16B, 185 PS | Listed at 1,040 kg without power steering and 1,050 kg with it, in Honda's launch table. |
| EK9 three-door hatchback (Japan) | TYPE R・X (from 16 December 1999) | B16B, 185 PS | Adds CD audio, keyless entry, aluminium-pad sports pedals and carbon-look panels to the TYPE R. |
Should You Buy a Honda Civic EK9?
Strengths and cautions come from Honda's launch material and UK buying guides.
Why You'll Love It
- Documented high-revving engine Honda rates the B16B at 185 PS net at 8,200 rpm and raised the engine speed limit from 8,200 to 8,400 rpm.
- Factory limited-slip differential Honda lists a torque-sensitive helical LSD on the TYPE R.
- Stiffened body Honda reports 35% more torsional rigidity than the base Civic, with added performance rods and a reinforced tailgate opening.
- Dated option history Honda's launch table, the September 1998 facelift and the December 1999 TYPE R・X give a dated trail for checking a car's grade.
Why You Might Not
- Grades differ in equipment and weight Race-base, equipment-delete and road cars carry different equipment and masses, so a car must be matched to its grade.
- No settled production number Honda's retrospective and a press report give different totals on different bases.
- Corrosion warnings UK guides flag the arches, the underside and the area under the boot carpet. That is condition advice from UK-used cars, not a measured Japanese failure rate.
Who Should NOT Buy This
- Anyone who judges authenticity by seats or air conditioning alone: Honda documented race-base and equipment-delete cars.
- Anyone who needs an exact build year from a catalogue: Honda's archive endpoint of September 2001 is not a production ledger.
- Anyone who cannot match the chassis code, engine and differential to the documented specification.
Common Issues & Solutions
These are inspection prompts from UK-used-car guides, not failure rates. No repair costs are given.
| Issue | Cause | Solution |
|---|---|---|
| Corrosion | Evo says to look for rust in the arches and underneath, and PistonHeads says to check under the boot carpet for holes. Both discuss UK-used cars, not a Japanese failure rate. | Inspect the arches, underside and boot floor, lifting the carpet. |
| Blue exhaust smoke | Evo advises treating puffs of blue smoke as a sign that serious care may be needed. It gives no cause or rate. | Check the exhaust at start-up and under load, ask about oil use, and have a compression or leak-down test done. |
| Gearbox and accident repair | PistonHeads recommends testing the gearbox thoroughly and checking for repaired accident damage. It is condition advice, not a measured defect rate. | Test every gear on a long drive and look for paint and panel mismatch. |
| Timing-belt history | The B16B's camshafts are belt-driven, and this research found no Honda Japan replacement interval. | Ask for dated belt-service evidence and have a competent mechanic inspect the car. |
Differences between JDM & USDM
This page describes the Japanese E-EK9 in Honda's own net PS figures. Evo reports that Honda never officially sold the car in the UK. Specifications of cars sold in other markets are not carried across, and this guide gives no figures for a European-market EK9 because none is established.
Pre-Purchase Inspection Checklist
Verify the grade, identity, condition, paperwork and import age in that order.
Critical Priority
High Priority
Medium Priority
Generation History
Generation span (Japan) (1997–2001)
- Announced and on sale 22 August 1997 through Honda's Primo dealers
- Honda's archive lists the model as announced in August 1997 and ended in September 2001; evo labels the car 1997–2000. The factory's last build month is not established
Facelift (3–4 September 1998)
- Honda announced the facelifted Civic range, including the Type R, on 3 September 1998 and sold it from 4 September
TYPE R・X (16 December 1999)
- Announced and sold from 16 December 1999, with CD audio, keyless entry, aluminium-pad sports pedals and carbon-look panels
Market Data
Rows follow Honda's documented grades: the road TYPE R, the race-base car and the TYPE R・X.
Reported Counts & Rarity
| Generation | Years | Reported Count | Notes |
|---|---|---|---|
| EK9 (Japan), Honda retrospective | Two-year period stated in the retrospective | About 15,900 sold | American Honda's Type R timeline gives about 15,900 sold over a two-year period it states. It is a sales figure on an ambiguous period, not a production ledger. |
| EK9 (Japan), press report | Whole generation, as reported | Just over 16,000 produced | A PistonHeads feature says Honda produced just over 16,000 EK9s for the Japanese market, 9,205 of them facelifted. It is not reconciled to a Honda ledger, and the facelift figure is not a TYPE R・X total. |
In Pictures
The Buyer's Read
Identify the grade before anything else. Honda documented a race-base car at launch, an equipment-delete option, a road TYPE R with Recaro seats and, from December 1999, the TYPE R・X. Missing seats or air conditioning can reflect the grade, so do not judge a car on one item.
Check the chassis code, the B16B and the helical differential together. Then inspect for the problems UK guides list: rust in the arches, underneath and beneath the boot carpet, blue exhaust smoke, a worn gearbox and unreported accident repair. These are condition advice from UK-used cars, not Japanese failure rates.
Ask for dated timing-belt records. Honda's archive ends the model in September 2001, but the factory's last build month is not established, and no reliable total production figure exists.
Work out import age from the build date, not the model year. For the US, 49 CFR 591.5(i) requires 25 years from manufacture, EPA's engine rule applies separately, and state rules vary. Canada uses 15 years from the manufacture month and year.
Frequently Asked Questions
- Was the EK9 sold new in the UK?
- No. Evo reports that Honda never officially sold the EK9 in the UK, so UK-registered cars are imports.
- How much power does the B16B make?
- Honda rates it at 185 PS net at 8,200 rpm, about 182.5 mechanical horsepower by conversion, with 16.3 kgf·m at 7,500 rpm (about 160 N·m). The engine speed limit is 8,400 rpm.
- What changed with the facelift?
- Honda announced the facelifted Civic range, including the Type R, on 3 September 1998 and put it on sale on 4 September. The launch dimensions in this guide apply to pre-facelift cars; a full facelift specification is not covered.
- When did the TYPE R・X appear?
- Honda announced and sold it from 16 December 1999. It added CD audio, keyless entry, aluminium-pad sports pedals and carbon-look panels to the TYPE R.
- What is a race-base EK9?
- Honda's August 1997 specification already lists a race-base car, at 1,040 kg without power steering. A PistonHeads feature describes a Motor Sports edition released in 1998; this guide does not equate the two.
- How many EK9s were made?
- No settled figure exists. Honda's American retrospective says about 15,900 were sold over a two-year period, and PistonHeads says just over 16,000 were produced for Japan, 9,205 of them facelifted. The bases differ.
- When can this car be imported to the US or Canada?
- The US 25-year rule is judged on each car's own build date, not its model year. EPA's separate age rule expects the original engine model and configuration. Canada counts 15 years from the manufacture month and year, and a province may still restrict registration.
